svelte-fluid

WebGL fluid simulation as a Svelte 5 component library.

Live demo

Why this library?

Other WebGL fluid packages are vanilla JS wrappers around the same upstream simulation. svelte-fluid is purpose-built for Svelte 5:

• True component API — <Fluid /> with 70+ typed props, live reactive updates, and full cleanup on unmount
• Multiple independent instances per page — no shared GL state
• Deterministic seeding — same seed reproduces the same splat pattern across resizes
• 10 presets — drop-in <LavaLamp />, <Aurora />, <CircularFluid />, <SvgPathFluid />, etc.
• 5 container shapes — circle, frame, roundedRect, annulus, and arbitrary SVG paths / text via mask texture
• Glass post-processing — refraction, specular highlights, and chromatic aberration on any container shape
• Lazy loading + auto-pause — defer engine creation until viewport entry
• Imperative API — splat() and randomSplats() via bind:this

Install

npm install svelte-fluid
# or
pnpm add svelte-fluid
# or
bun add svelte-fluid

Requires Svelte ≥ 5.

Quick start

<script lang="ts">
  import { Fluid } from 'svelte-fluid';
</script>

<div style="width:100%; height:100vh">
  <Fluid />
</div>

That's the entire setup. The canvas fills its parent and tracks parent size via ResizeObserver.

For a first-run screen that shows motion immediately in a blank app, start with a slightly brighter starter config:

<div style="width:100%; height:100vh">
  <Fluid
    seed={42}
    initialSplatCount={20}
    autoSplatRate={0.25}
    autoSplatCount={2}
    densityDissipation={0.35}
    velocityDissipation={0.08}
    curl={45}
    splatRadius={0.35}
    bloomIntensity={1.2}
    sunraysWeight={0.6}
    backColor={{ r: 6, g: 10, b: 26 }}
  />
</div>

Fixed dimensions

<Fluid width={400} height={300} />

Custom physics

<Fluid
  curl={20}
  splatRadius={0.5}
  bloom={false}
  shading
  densityDissipation={0.4}
  initialSplatCount={12}
  seed={42}
/>

Imperative API via bind:this

<script lang="ts">
  import { Fluid, type FluidHandle } from 'svelte-fluid';

  let ref = $state<{ handle: FluidHandle } | undefined>();
</script>

<button onclick={() => ref?.handle.randomSplats(10)}>Splat!</button>
<Fluid bind:this={ref} />

Browser compatibility

• WebGL 1 (with linear filtering) and WebGL 2 both work
• Tested on Chrome 120+, Firefox 121+, Safari 17+
• Mobile: works on iOS Safari 16+ and Chrome Android, with lazy={true} strongly recommended on dense pages
• Linear filtering fallback: when OES_texture_float_linear is unavailable, the engine drops shading, bloom, sunrays and clamps dyeResolution ≤ 512 — see FluidEngine.initContext()

Props

All props are optional. CamelCase wraps the original SCREAMING_CASE config from the upstream project.

The component also forwards any standard <canvas> attributes (class, style, aria-label, …) onto the underlying canvas via ...rest.

Presets

Ten opinionated wrapper components ship alongside <Fluid />. Each one hard-codes a physics + visual configuration and (for most of them) a hand-crafted set of opening splats so you can drop them in without any tuning:

<script lang="ts">
  import { LavaLamp, Plasma, ToroidalTempest } from 'svelte-fluid';
</script>

<div style="height: 100vh">
  <LavaLamp />
</div>

<div style="display:grid; grid-template-columns:repeat(2, 1fr); gap:16px">
  <Plasma />
  <ToroidalTempest />
</div>

Each preset forwards a small common set of props: width, height, class, style, seed, lazy, and aria-label. Some shape presets also expose small shape-specific knobs such as splatOnHover or corner radii. The main physics recipe is intentionally fixed. They all re-expose the imperative handle so you can still call splat() / randomSplats() from outside via bind:this.

Building your own preset

A preset is a tiny wrapper around <Fluid /> that pins config and optionally passes a presetSplats array. The engine consumes presetSplats once at construction (right after the random initial splats), so the opening scene is fully deterministic and reproducible across resizes.

<script lang="ts">
  import { Fluid, type PresetSplat, type FluidHandle } from 'svelte-fluid';

  const SPLATS: PresetSplat[] = [
    { x: 0.5, y: 0.1, dx: 0, dy: 800, color: { r: 1.6, g: 0.4, b: 0.1 } }
  ];

  let inner = $state<{ handle: FluidHandle } | undefined>();
  export const handle: FluidHandle = {
    splat: (x, y, dx, dy, c) => inner?.handle.splat(x, y, dx, dy, c),
    randomSplats: (n) => inner?.handle.randomSplats(n)
  };
</script>

<Fluid
  bind:this={inner}
  curl={50}
  densityDissipation={0}
  initialSplatCount={0}
  presetSplats={SPLATS}
/>

Note: presetSplats is construct-only — like seed, changes after mount are ignored. To paint a new scene, change the seed (which forces a teardown/rebuild) or call handle.splat() imperatively.

Splat coordinates are normalized: x ∈ [0,1] left-to-right and y ∈ [0,1] bottom-to-top. Color components are in 0–1 range; values above 1 are valid and read as HDR highlights through the bloom pass.

Burn-in density dissipation

If you want a densityDissipation: 0 "vivid persistent" look but the opening splats are bright enough to overwhelm the canvas, use a temporary high dissipation that decays to zero:

<Fluid
  densityDissipation={0}
  initialDensityDissipation={1.5}
  initialDensityDissipationDuration={2}
  presetSplats={SPLATS}
/>

The engine linearly interpolates from initialDensityDissipation → densityDissipation over initialDensityDissipationDuration seconds, then holds at the steady-state value forever. This lets the overlapping additive splats "burn in" — overbright pixels fade for the first couple of seconds — before dissipation locks at zero so the remaining dye persists indefinitely. The LavaLamp and Plasma presets use this pattern.

The clock starts when the engine begins ticking (post-mount, post first ResizeObserver fire), so the burn-in survives setConfig updates and matches the user's perception of "since the canvas appeared".

Container shapes

Confine the fluid to a geometric region with containerShape. The simulation physically enforces the boundary — velocity is zeroed outside and dye is masked after advection.

<!-- Circle -->
<Fluid containerShape={{ type: 'circle', cx: 0.5, cy: 0.5, radius: 0.45 }} />

<!-- Frame (fluid fills the border region around a rectangular cutout) -->
<Fluid containerShape={{ type: 'frame', cx: 0.5, cy: 0.5, halfW: 0.25, halfH: 0.25 }} />

<!-- Rounded rectangle -->
<Fluid containerShape={{ type: 'roundedRect', cx: 0.5, cy: 0.5, halfW: 0.35, halfH: 0.25, cornerRadius: 0.05 }} />

<!-- Annulus (ring between two circles) -->
<Fluid containerShape={{ type: 'annulus', cx: 0.5, cy: 0.5, innerRadius: 0.15, outerRadius: 0.4 }} />

<!-- SVG path -->
<Fluid containerShape={{ type: 'svgPath', d: 'M50 5 L61 40 L98 40 L68 62 L79 97 L50 75 L21 97 L32 62 L2 40 L39 40 Z' }} />

<!-- Text (fluid-filled letters) -->
<Fluid containerShape={{ type: 'svgPath', text: 'HELLO', font: 'bold 72px sans-serif' }} />

Coordinates are normalized: cx/cy in [0, 1] (left-to-right, bottom-to-top). radius is normalized by canvas height. The svgPath type rasterizes to a mask texture via OffscreenCanvas and supports both SVG path data (d) and Canvas 2D text (text).

Glass effect

Add a glass post-processing layer to any container shape with glass. Circles get a hemisphere dome with Snell's law refraction; all other shapes get rim refraction at the boundary.

<!-- Glass orb with chromatic aberration -->
<Fluid
  containerShape={{ type: 'circle', cx: 0.5, cy: 0.5, radius: 0.4 }}
  glass
  glassRefraction={0.6}
  glassChromatic={0.3}
/>

<!-- Subtle glass frame -->
<Fluid
  containerShape={{ type: 'frame', cx: 0.5, cy: 0.5, halfW: 0.3, halfH: 0.2 }}
  glass
  glassThickness={0.06}
  glassReflectivity={0.08}
/>

The specular highlight tracks the mouse cursor automatically. All highlights are driven by the fluid brightness — no fluid, no highlights.

FluidBackground composition

FluidBackground is a page or screen wrapper, not a local card widget. Its fluid canvas is fixed to the viewport, and its slotted content sits above the canvas with pointer-events: none so window-level pointer input keeps feeding the simulation.

Keep elements inside the slot when they should carve holes in the fluid via exclude. Add pointer-events: auto back to interactive children such as nav bars, cards, and forms:

<script lang="ts">
  import { FluidBackground } from 'svelte-fluid';
</script>

<FluidBackground class="fluid-screen" exclude=".site-nav, .panel" splatOnHover>
  <nav class="site-nav">...</nav>
  <main class="hero-copy">...</main>
  <section class="panel">...</section>
</FluidBackground>

<style>
  :global(.fluid-screen) {
    min-height: 100vh;
    isolation: isolate;
  }

  .site-nav,
  .panel {
    position: relative;
    z-index: 2;
    pointer-events: auto;
  }

  .hero-copy {
    position: relative;
    z-index: 1;
  }
</style>

For a local bounded canvas, use <Fluid /> with a parent size or fixed width / height instead.

Resize behavior

A ResizeObserver watches the wrapper container. Whenever the CSS dimensions change, the engine is fully torn down and reinstantiated with the same seed, so the initial splat pattern is identical. If you don't provide a seed, the component generates one once at mount and reuses it across resizes.

Multiple instances

Each <Fluid /> owns its own WebGL context, framebuffers, RAF loop, listeners, and pointer state. Browsers cap simultaneous WebGL contexts at 8–16 per tab, so plan accordingly for very dense layouts.

For pages with more than ~6 simultaneous instances, pass lazy={true} on each one. The component will then defer engine creation until the container enters the viewport (with a 200px lookahead) and tear it down when it leaves, keeping the live context count bounded:

<LavaLamp lazy />
<Plasma lazy />

The cost is a one-time shader-recompile pause (~100–500ms) when an instance scrolls back into view. For demo / showcase pages this is hidden behind the user's scroll momentum and rarely noticed.

Programmatic engine

If you need raw control without the Svelte component:

import { FluidEngine } from 'svelte-fluid';

const canvas = document.querySelector('canvas')!;
canvas.width = canvas.clientWidth * devicePixelRatio;
canvas.height = canvas.clientHeight * devicePixelRatio;

const engine = new FluidEngine({
  canvas,
  config: { curl: 20, bloom: false, seed: 42 }
});

// later…
engine.splat(0.5, 0.5, 100, 0, { r: 1, g: 0.5, b: 0 });
engine.randomSplats(8);
engine.setConfig({ curl: 5 });
engine.dispose();

Development

This project uses bun.

bun install
bun run dev      # demo playground at http://localhost:5173
bun run check    # svelte-check
bun run package  # produces dist/ with svelte-package
bun run build    # builds the SvelteKit demo site

Contributing

See CONTRIBUTING.md for local setup, architecture rules, and common workflows. Please open an issue before starting large changes.

Acknowledgments

This library is a derivative work of PavelDoGreat/WebGL-Fluid-Simulation, the original 2017 WebGL implementation by Pavel Dobryakov. The shader sources are reused unchanged. Both the upstream project and this port are MIT-licensed; see LICENSE for the full notices.

The reveal and distortion effects were inspired by Ksenia Kondrashova's creative WebGL demos built on the same fluid simulation.
