Muximux

A self-hosted homelab dashboard with an optional built-in reverse proxy that makes stubborn apps work in iframes.

One binary. One port. One YAML config file.

AI Disclosure -- Muximux is developed with significant AI assistance (Claude Code). All code is reviewed, tested, and approved by the maintainer before shipping. See Development for details.

More screenshots — onboarding wizard, light mode, themes, split view, command palette

Dashboard (Light)	Onboarding — Welcome	Onboarding — Security
Onboarding — App Catalog	Onboarding — Apps Configured	Onboarding — Style
Onboarding — Themes (Dark)	Onboarding — Themes (Light)	Onboarding — Done
Real-Time Log Viewer	Theme Selector	Theme Customizer
Split View — Horizontal	Split View — Vertical	Command Palette

What Is Muximux?

There's a good chance you already have a homelab dashboard. Homepage, Homarr, Organizr, and Dashy are all excellent tools in this space. If one of them already fits your workflow, you probably don't need to read further.

Muximux is built for a specific kind of user: someone who spends the day working inside their self-hosted apps, not glancing at widgets on a landing page. Click Sonarr and Sonarr opens inside the dashboard. Click Plex and Plex does too. No new tabs, no context switches. You never actually leave Muximux.

Making apps embed reliably is where it gets interesting. Most self-hosted apps set X-Frame-Options: DENY and refuse to load in an iframe. Muximux includes a built-in reverse proxy that strips those headers, rewrites paths in HTML/CSS/JS, and patches fetch() and XMLHttpRequest at runtime so even heavy single-page apps work the way they do when opened directly. Most dashboards point at your apps. Muximux makes them actually embed.

There are things Muximux deliberately doesn't do. It doesn't pull live widgets from Sonarr or qBittorrent (Homepage is lovely at that). It doesn't have a drag-and-drop visual editor (Homarr excels there). It doesn't have Dashy's breadth of built-in monitoring widgets. It's focused on one thing: making apps work side by side inside a single tab, polished enough to live in.

Everything is configured in one YAML file, no database, no external dependencies. The entire application ships as a single binary with the frontend embedded. Every setting is configurable through the built-in GUI, so you never have to touch the YAML directly. Back up or migrate your entire setup by copying a single file.

How does it compare?

The dashboards in this space approach things differently. This table is a quick way to see where each one leans.

If the rows near the top describe what you want, keep reading.

Why v3?

Muximux v3 is a ground-up rewrite. The original Muximux was a PHP application that served as a simple bookmark portal. v3 replaces it with a modern stack and a much broader feature set:

• Go backend with the frontend embedded in the binary - no PHP, no web server, no runtime dependencies
• Built-in reverse proxy that rewrites HTML, CSS, JS, and headers so apps actually work inside iframes
• Real-time health monitoring via WebSocket - see which apps are up or down without refreshing
• Built-in authentication - username/password, forward auth (Authelia/Authentik), or OIDC
• Optional TLS and gateway - an embedded Caddy instance can handle HTTPS certificates and serve other sites alongside Muximux
• Guided onboarding - a setup wizard walks you through security setup and adding your first apps
• Split view - display two apps side by side or stacked with a draggable divider
• 1,600+ icons from Lucide plus thousands of service-specific icons from Dashboard Icons
• Themes - built-in light and dark modes, plus custom themes via CSS

How You Can Use It

Muximux fits different setups. Pick the level that matches yours.

Dashboard behind your existing proxy

You already have Traefik, nginx, or Caddy handling TLS and auth. Run Muximux behind it with auth: none and let your proxy do the heavy lifting. Muximux serves on a single port and your proxy forwards to it. This is the simplest setup.

Dashboard with the built-in reverse proxy

Same as above, but some of your apps refuse to load in iframes. Set proxy: true on those apps and Muximux will proxy them through /proxy/{slug}/, stripping blocking headers and rewriting paths. This runs inside the Go server and works in every deployment mode - no extra configuration needed.

Full reverse proxy appliance

No existing proxy? Use Muximux as your only reverse proxy. Configure tls.domain for automatic HTTPS via Let's Encrypt and a gateway Caddyfile to serve your other services on their own domains. Caddy handles TLS certificates, HTTP-to-HTTPS redirects, and routing - all from the same single binary.

See the Deployment Guide for Docker Compose examples for each setup.

Quick Start

Docker

docker run -d \
  --name muximux \
  -p 8080:8080 \
  -v $(pwd)/data:/app/data \
  ghcr.io/mescon/muximux:latest

Open http://localhost:8080. If no config file exists, an onboarding wizard will guide you through security and initial setup.

Docker Compose

services:
  muximux:
    image: ghcr.io/mescon/muximux:latest
    ports:
      - "8080:8080"
    volumes:
      - ./data:/app/data
    restart: unless-stopped

Binary

./muximux

By default, Muximux uses data/ beside the binary as its data directory (containing config, themes, icons). Override it with --data or the MUXIMUX_DATA environment variable.

See docker-compose.yml for a full example with environment variables, health checks, and optional TLS/gateway ports.

Documentation

Full documentation is available in the Wiki:

• Installation - Docker, binary, building from source
• Getting Started - First launch and onboarding
• Configuration Reference - All config.yaml options
• Apps - Adding and configuring applications
• Built-in Reverse Proxy - How the proxy works and when to use it
• Security - Security measures and OWASP ASVS compliance
• Authentication - Auth methods and setup
• TLS & HTTPS - Certificates and gateway mode
• Deployment Guide - Production deployment examples
• Split View - Side-by-side or stacked app panels
• Themes - Customizing the look
• API Reference - REST API endpoints

Configuration at a Glance

Everything lives in one YAML file. Here's the essentials:

server:
  listen: ":8080"
  title: "My Homelab"

apps:
  - name: Sonarr
    url: http://sonarr:8989
    icon: { type: dashboard, name: sonarr }
    group: Media
    proxy: true            # Proxy through /proxy/sonarr/
    open_mode: iframe      # iframe, new_tab, new_window, redirect

  - name: Grafana
    url: http://grafana:3000
    icon: { type: dashboard, name: grafana }
    group: Monitoring

groups:
  - name: Media
    icon: { type: lucide, name: play }
    color: "#e5a00d"

  - name: Monitoring
    icon: { type: lucide, name: activity }
    color: "#27ae60"

Configuration values can reference environment variables (${OIDC_CLIENT_SECRET}), and the listen address can be overridden via --listen flag or MUXIMUX_LISTEN env var. The data directory (where config, themes, and icons live) defaults to data/ beside the binary and can be set via --data or MUXIMUX_DATA.

For the full configuration reference, authentication options, TLS setup, and more, see the Wiki.

Features

Project Philosophy

Muximux aims to be a solid, focused piece of software. The goal is a homelab dashboard that does its job well - not a monitoring suite, not a system management tool, not a kitchen sink. Features are evaluated by whether they serve the core purpose: giving you a single page to access and organize your self-hosted apps.

Suggestions and ideas are always welcome. Not everything will make it in, but that's by design - quality over quantity, and the project is better for it.

Development

Muximux is developed using Claude Code (Opus 4.6) with MCP servers for browser automation (Playwright), GitHub integration, and other validation tools. It's a heavily AI-assisted workflow, but all code is reviewed, tested, and committed by the sole maintainer. AI output is treated the same way as a pull request from a contributor - nothing ships without understanding and approval.

Every push goes through CI with 86%+ backend and 87%+ frontend test coverage, golangci-lint, ESLint, svelte-check, CodeQL analysis, Snyk vulnerability scanning (Go, Node, Docker), govulncheck, SonarCloud quality gates, and a pre-push hook that blocks pushes below coverage thresholds. The security model is designed against OWASP ASVS Level 2.

git clone https://github.com/mescon/Muximux.git
cd Muximux

# Enable git hooks (pre-push runs tests with coverage checks)
git config core.hooksPath .githooks

# Frontend dev server (hot reload)
cd web && npm install && npm run dev &

# Backend (uses data/ beside the binary by default for config, themes, icons)
go run ./cmd/muximux

Building

# Build frontend (outputs to internal/server/dist/)
cd web && npm run build && cd ..

# Build binary (embeds frontend)
go build -tags embed_web -o muximux ./cmd/muximux

# With version info (uses latest git tag)
go build -tags embed_web -ldflags "-X main.version=$(git describe --tags --abbrev=0)" -o muximux ./cmd/muximux

License

GPL v2 - see LICENSE for details.

Credits

• Lucide Icons for the icon library
• Dashboard Icons by Homarr Labs
• Caddy for embedded TLS and gateway support

Star History
